Item
|
Details
|
|
DFM Analysis
|
Feer Cost
|
|
Cavity & Core Inserts
|
P20H, 718H, 718, 2738, 2767, NAK80, SKD11, S316H, 2344, H13, S50C, S45C, or customers' appointed
|
|
Mold Base
|
LKM, HASCO, DME or upon customer's requirement
|
|
Gate Method
|
Subgate /Banana gate; Side gate; Valve gate; Disc film gate and so on
|
|
Ejector System
|
Ejector Pin, Ejector Plate, Ejector Sleeve, Ejector Block, Air Ejection, Hydraulic Ejection, Lifter Ejection, Spring Ejection
|
|
Mold Life
|
10,000-1,000,000 shots
|
|
Cavities
|
Single/Multi
|
|
Product Material
|
PEEK, Nylon, PFA, PVDF, PTFE, PEI, PPS, PES, PPSU, POM, PMMA, PP, TPE, ASA, ABS, PC, PE, TPU, HDPE, etc
|
|
Runner
|
Hot/Cold runner system
|
|
Drawing Format
|
dwg, dxf, pdf, stp, step, igs, x-t
|
|
Software
|
CAD, UG
|
|
Surface Finish
|
Industrial polish, EDM texture, Etching tecture, Polishing finish, Texture Finish, Glossy Finish, Painting etc
|
|
Specification
|
Follow the 3D final drawing or 2D drawings or part samples
|
|
Packaging details
|
Vacuum package with plywood box
|
|
Delivery Terms
|
EXW, FOB, CIF
|
|
Shipping Methods
|
By sea; By air; By train; Express delivery
|
|
Lead Time
|
1week - 6weeks
|
Our Service
Winzun – Complete Solutions for Injection Molding
✅ One-stop service – From product design, mold design, and manufacturing, to injection molding, printing, assembly, packaging, and shipping – we handle it all.
✅ Free design & DFM support – Send us a sample or sketch; our designers provide free product design, plus optimization suggestions in a detailed DFM report.
✅ Mold fee refund – Reach an agreed order quantity and we will refund your full mold investment.
✅ Express mold service – Need urgent T0 samples? We deliver within 10 days.
✅ Complex projects welcome – We thrive on challenges and have a proven track record of turning innovative ideas into production realities.
✅ Customer-first approach – From small trials to high-volume runs, we value every client. With precision, cost-effectiveness, and dedicated service, let’s start your project today. We look forward to a long-term partnership!
Winzun – Injection Molding & Finishing Capabilities
✅ Custom-made plastic enclosures with various surface finishing: painting, printing, water transfer printing, welding, assembly, and more.
✅ Injection molding services for diverse industries – from automotive to consumer electronics.
✅ Flexible production volumes: low-volume prototyping to high-volume mass production.
✅ Advanced molding processes: two-shot (two-color) and insert molding.
✅ Class 10K & 100K cleanrooms for medical, food-grade, and high-precision electronics.
✅ Press capacity: 80T to 1000T, covering micro parts, thin-walled parts, and large components.
✅ Precise color matching according to PANTONE or RAL standards.
✅ Complete secondary operations: ultrasonic welding, gluing, pad printing, plating, and packaging.
✅ Robotic automation ensures consistent quality and cost savings.
